The prevalence of extramedullary acute myeloid leukemia detected by 18FDG-PET/CT: final results from the prospective PETAML trial

Abstract

Extramedullary (EM) disease in patients with acute myeloid leukemia (AML) is a known phenomenon. Since the prevalence of EM AML has so far only been clinically determined on examination, we performed a prospective study in patients with AML. The aim of the study was to determine the prevalence of metabolically active EM AML using total body ¹⁸Fluorodesoxy-glucose positron emission tomography/computed tomography (¹⁸FDG-PET/CT) imaging at diagnosis prior to initiation of therapy. In order to define the dynamics of EM AML throughout treatment, PET-positive patients underwent a second ¹⁸FDG-PET/CT imaging series during follow up by the time of remission assessment. A total of 93 patients with AML underwent ¹⁸FDG-PET/CT scans at diagnosis. The prevalence of PET-positive EM AML was 19% with a total of 65 EM AML manifestations and a median number of two EM manifestations per patient (range, 1-12), with a median maximum standardized uptake value of 6.1 (range, 2-51.4). When adding those three patients with histologically confirmed EM AML who were ¹⁸FDG-PET/CT negative in the ¹⁸FDG-PET/CT at diagnosis, the combined prevalence for EM AML was 22%, resulting in 77% sensitivity and 97% specificity. Importantly, 60% (6 of 10) patients with histologically confirmed EM AML still had active EM disease in their follow up ¹⁸FDG-PET/CT. ¹⁸FDG-PET/CT reveals a high prevalence of metabolically active EM disease in AML patients. Metabolic activity in EM AML may persist even beyond the time point of hematologic remission, a finding that merits further prospective investigation to explore its prognostic relevance. (Trial registered at clinicaltrials.gov identifier: 01278069.)

Introduction

Acute myeloid leukemia (AML) may present with either concomitant or isolated extramedullary (EM) AML, also termed myeloid sarcoma (MS). EM AML is defined by infiltrating AML blasts effacing normal tissue as demonstrated by histological evaluation.1 Data on the prevalence of EM AML are based on retrospective or clinical analyses, and they possibly under-estimate the true prevalence, since they rely on findings from physical examination only or on coincidental findings in standard imaging procedures. Others have performed retrospective analyses from autopsy series, which might over-estimate the prevalence of EM AML, since these series accumulate data on AML patients succumbing to their disease. So far, EM AML prevalence has been seen to range from 2.5% to 9.1%.32 Previous studies and AML treatment recommendations identified EM AML as an adverse prognostic factor in patients with AML.4 In contrast, a recent retrospective analysis based on clinical data from a large number of AML patients included in clinical trials revealed a high proportion of patients with EM AML (23.7%), but could not identify EM AML as an independent prognostic factor.5 Nevertheless, this analysis and others also included patients with, for example, hepatomegaly and/or splenomegaly, gingival hyperplasia based on clinical examination, suggesting these represent EM AML or leukemic meningitis. These findings per se do not fulfill the criteria for EM AML.65 However, without a precise assessment of EM AML, valid risk factor analyses cannot be performed. Fluorodesoxy-glucose positron emission tomography/computed tomography (FDG-PET/CT) is able to detect highly metabolic tissue and has proven efficacy in imaging studies for various types of malignant diseases. We and others have demonstrated the utility of FDG-PET/CT imaging in AML patients with histologically proven EM AML.137 We were able to demonstrate a sensitivity of 90% using FDG-PET/CT imaging and found additional EM sites in 60% of the patients.8 Another study in ten unselected AML patients using Fluorodeoxythymidine-PET discovered EM AML in 4 of 10.14 Prospective studies to assess the prevalence of EM disease in AML in unselected patients have, so far, not been performed. The aim of this prospective, observational study was to use FDG-PET/CT to determine the prevalence of EM AML in patients prior to initiation of AML therapy.

Methods

This open, prospective observational study was approved by the institutional review board (EK309102009) and registered at clinicaltrials.gov identifier: 01278069. Informed consent was collected prior to the first PET scan. Patients with AML aged 18-80 years underwent baseline total body FDG-PET/CT scans before initiation of therapy. Patients were included only if a delay of ≤5 days of initiation of treatment was clinically justifiable in order to perform the study.15 Hydroxyurea for disease control was admissible before the FDG-PET/CT. The primary objective of this study was to determine the prevalence of EM AML at diagnosis. The sample size was calculated such that the width of the 95% confidence interval (CI) would stay within 20%. Assuming a prevalence of 40% EM AML, 93 patients would need to be studied. The prevalence of 40% was based on the only data available at the time from a case series of ten unelected patients undergoing PET/CT scanning, demonstrating existence of EM AML in 4 of those 10 patients.14 This trial was not powered to compare survival differences in EM AML as compared to AML patients without EM. Since there is no evidence to indicate that the treatment of AML patients with EM manifestation of AML needs to be intensified or modified, the presence of EM AML was not part of the decision-making process for treatment of these patients.

In total, 106 patients were screened for the study between February 2011 and July 2013 in the Department of Haematology of the University Hospital Dresden. Of those, 13 patients were considered to be screening failures and were not considered for further analyses, such that the planned sample size of 93 patients was reached. Reasons for screening failure were: age >80 years or FDG-PET/CT not feasible due to the clinical condition of the patient (n = 7) or other (n=6). Interestingly, two of these 13 patients had EM AML (histologically confirmed diagnosis in one patient and clinical diagnosis in the other). Patients with PET-positive EM AML at baseline underwent a second FDG-PET/CT scan after therapy initiation either at the date of complete remission or until day 60 in case of not achieving CR. A complete diagram of screened and included patients is shown in Figure 1. Hybrid FDG-PET/CT scans were performed as recently published using a Siemens Sensation 16 as part of a bio-graph (Siemens, Knoxville, TN, USA) with intravenous application of FDG and 120 mL contrast media Ultravist 370 (Bayer Schering Pharma, Leverkusen, Germany).8 PET 3-dimensional emission scans were conducted with a median activity of 367 MBq (range, 223-433 Mbq), as recently published.8 For assessment of FDG-PET/CT imaging, no specific threshold or metabolic activity (e.g. maximum standardized uptake value, SUVmax) was applied. Instead, subtle correlation of any FDG-positive lesion with the fused CT images was performed to detect a corresponding tissue proliferation before suspecting an EM manifestation of AML. In cases in which no morphological correlate was apparent, FDG-positive lesions were declared to be unspecific. The estimated prevalence of EM AML was ascertained by calculating the specificity of baseline FDG-PET/CT positivity in relation to those EM AML lesions confirmed positive for EM AML upon histology. Thereafter, the total number of baseline FDG-PET/CT positive EM AML patients was multiplied by this specificity to derive an estimate for the prevalence in the total sample of 93. A CI with at least 95% coverage was derived by calculating the exact Clopper-Pearson-Confidence Intervals. Complete remission (CR) was defined according to the standard consensus criteria.16 The Mann-Whitney U-test was used to compare continuous variables between patient groups, while the χ-test was applied to categorical variables. All statistical analyses were performed using SPSS version 25 (SPSS Inc., Chicago, IL, USA); two-sided tests were applied. P<0.05 was considered statistically significant.

Figure 1.Modified CONSORT diagram demonstrating screening, patient selection and analysis for the complete patient cohort. PETAML: PET-CT in AML for Detection of Extramedullary AML Manifestations study; n: number; ¹⁸FDG-PET/CT: ¹⁸Fluorodesoxy-glucose positron emission tomography/computed tomography; EM: extramedullary; AML: acute myeloid leukemia.

Results

Patient population and safety

A total of 93 patients with AML (n=9 with relapsed AML) underwent total body FDG-PET/CT scans at diagnosis after giving informed consent. Median age of all patients was 61 years (range, 27-79 years). Clinical characteristics of the patient population are shown in Table 1. The majority were diagnosed with de novo AML (n=53, 57%) while 22 patients (23%) had secondary AML after preceding myelodysplastic syndrome (MDS)/myeloproliferative neoplasm (MPN), and n=18 (19%) patients had therapy-related AML (tAML)/therapy-related MPN (tMN). Median follow up of alive patients is 46 months (range, 5-60 months). There were no adverse reactions due to the application of intravenous FDG and intravenous contrast media. No deterioration in renal function, as determined by measurement of creatinine serum levels and estimation of GFR (eGFR) by Cockroft-Gault, was observed after FDG-PET/CT imaging.

Table 1.Patients’ characteristics at diagnosis.

Prevalence and sites

Total body FDG-PET/CT imaging detected highly metabolic manifestations suggestive of EM AML in 23% of the enrolled patients (n=21). Of these FDG-PET positive patients, 11 (52%) had de novo AML, while 7 (33%) had tAML and 3 (14%) secondary AML with preceding MDS/MPN. In total, 65 EM AML manifestations were identified with FDG-PET/CT in these 21 patients. The median SUVmax was 6.1 (range, 2-51.4). Patients with EM AML as per FDG-PET/CT had a median of two EM AML manifestations (range, 1-12) with only six patients having only one EM AML manifestation; exemplary FDG-PET/CT imaging is depicted in Figures 2A and B and 3A and 3B. Sites of EM AML as detected per FDG-PET/CT were connective tissue (n=4, one patient paravertebral, one paraaortic, one next to the jaw angle, and one at the base of the tongue), parenchymal tissues (n=8, with manifestations in adrenal glands, kidneys, liver, and spleen), and lymph nodes (n=15). A total of 9% of patients presented with clinically overt EM AML (n=8). Applying FDG-PET/CT, additional EM manifestations were detected in 62% (n=5) of these patients. In 12 of the 21 patients who were diagnosed with EM AML as per FDG-PET/CT, biopsies from EM sites were obtained in order to assess the provenance of the diagnosed tumor and to assess the sensitivity of FDG-PET/CT. In ten patients, histology review confirmed the occurrence of EM AML in these sites, indicating a sensitivity of 77% for FDG-PET/CT. Interestingly, in the two remaining patients in whom histology could not confirm EM AML, concomitant tumors were found (one patient with Castleman’s disease and one patient with a solid fibrous tumor). Extrapolating these results onto the entire cohort, and applying the positive predictive value of 83.3%, the prevalence of EM AML in our AML patient cohort was 17% (95%CI: 11-29%). When only analyzing patients with newly diagnosed AML, 16 (19%) patients were identified with EM AML as per FDG-PET/CT. Characteristics of patients with or without EM AML as per FDG-PET/CT and histological confirmation are shown in Online Supplementary Table S1. In comparison with PET-negative patients, those with PET-positive EM AML as per FDG-PET/CT had a higher percentage of bone marrow infiltrating blasts, higher white blood cell (WBC) count in the peripheral blood, and higher C-reactive protein serum levels. Furthermore, in the cohort of AML patients with EM disease, there were no patients with favorable cytogenetic risk and a higher fraction of patients with relapsed AML.

Figure 2.Images of a 69-year old female patient with histologically confirmed extramedullary (EM), bilobular hepatic manifestations of acute myeloid leukemia (AML) (continuous arrows) who underwent intensive induction chemotherapy. (A) Maximum intensity projection (MIP) and (B) three representative slices of the fused multiplanar reconstructions (MPR) of the pre-therapeutic ¹⁸Fluorodesoxy-glucose positron emission tomography/computed tomography (¹⁸FDG-PET/CT). Maximum standardized uptake value (SUVmax) ranged from 5.2 to 7.4. (C) MIP of the post-therapeutic ¹⁸FDG-PET/CT confirming a complete metabolic remission of all hepatic lesions. Note the hypermetabolic focus (SUVmax 8.9) in the right thyroid lobe (dotted arrows, see also (A) at baseline) which does not reflect AML but rather a thyroid adenoma that was still present in the post-therapeutic scan (SUVmax 8.1).

Figure 3.Images of a 63-year old female patient with histologically confirmed extramedullary (EM) manifestation of acute myeloid leukemia (AML) in the oral cavity (dotted arrows) who underwent intensive induction chemotherapy. (A) Maximum intensity projection (MIP) and (B) fused multiplanar reconstruction (MPR) of the pre-therapeutic ¹⁸Fluorodesoxy-glucose positron emission tomography/computed tomography (¹⁸FDG-PET/CT). Maximum standardized uptake value (SUVmax) was 9.1. ¹⁸FDG-PET detected a further right iliac EM AML (SUVmax 5.6; continuous arrows). (C) MIP of the post-therapeutic follow up ¹⁸FDG-PET/CT confirming the slightly regressive EM AML of the oral cavity (SUVmax 7.4) but also the progressive right iliacal EM AML (SUVmax 8.1). (D) MPR of this scan. New bicervical EM AML (dashed arrows) was also detected (E), see also (C) (SUVmax up to 9.5).

In addition, in three patients of the FDG-PET/CT negative group (n=72), EM AML was identified on examination and diagnosed through histological confirmation after biopsy. Two of these patients had a skin manifestation (chloroma) while one patient developed cervical lymphadenopathy during induction chemotherapy and then underwent biopsy and an additional, unscheduled FDG-PET/CT, both confirming the diagnosis of EM AML. When these patients were added to our extrapolated prevalence of EM AML, the combined prevalence of EM AML in this study was 22%. Thus, the specificity for FDG-PET/CT to detect EM AML is 97%. An overview of patients undergoing biopsy for diagnosis in both cohorts is available in the Online Supplementary Table S2. When we analyzed only the largest subgroup of our study cohort of patients with newly diagnosed AML, the combined prevalence of EM AML was 17%.

A total of 18 patients (19%) in this study were treated with hydroxyurea prior to FDG-PET/CT and thus prior to initiation of chemotherapy. Four of the 21 patients (19%) who were diagnosed with EM AML as per FDG-PET/CT were treated with hydroxyurea prior to FDG-PET/CT imaging.

Follow-up 18FDG-PET/CT

Patients with EM diagnosed by FDG-PET/CT underwent a second FDG-PET/CT scan at confirmation of CR or, at the latest, until day 60 after initiation of therapy in case no CR was achieved. A total of 14 of 21 patients with EM AML as per baseline FDG-PET/CT at diagnosis underwent a second FDG-PET/CT. The remaining patients did not undergo a second FDG-PET/CT because of severe disease and intensive care treatment (n=3), mental distress (n=1), palliative care in a hospice (n=1), and withdrawal of study consent for the second FDG-PET/CT (n=2). When we analyzed only the follow upFDG-PET/CT of those patients who were FDG-PET/CT positive and had a positive confirmatory biopsy (n=10 patients), 60% of these patients (n=6) were still positive for EM AML as diagnosed per the second FDG-PET/CT. Exemplary FDG-PET/CT imaging of a responding and a non-responding patient (who both underwent intensive induction chemotherapy) is available in Figures 2C and 3C-E. Interestingly, of the six patients who still had EM AML (as per FDG-PET/CT imaging) at the time of their second FDG-PET/CT, four patients with EM AML and AML bone marrow infiltration at diagnosis were in CR as determined by bone marrow cytomorphology at the time of second FDG-PET/CT. Of those four patients who still had EM AML in their second FDG-PET/CT, but who were in CR as per bone marrow cytomorphology, three patients subsequently relapsed. The other two (of the six patients with persistent metabolic disease) had isolated EM AML as per FDG-PET/CT: one patient had unchanged EM AML manifestations in the second FDG-PET/CT, while the other had a progression of EM AML manifestations in the second FDG-PET/CT. The metabolic and numerical dynamics of EM AML manifestations in patients with histologically confirmed EM AML from baseline to follow up FDG-PET/CT are shown in Online Supplementary Figure 1A and B.

Discussion

Our study is the first to prospectively evaluate FDG-PET/CT imaging for the diagnosis of EM AML in patients with AML. Furthermore, this is the first prospective study combining FDG-PET/CT imaging, clinical findings, and histological examination after biopsy to systematically estimate EM AML. According to our results, FDG-PET/CT is a useful and safe tool to detect EM AML with a high sensitivity and specificity of 77% and 97%, respectively. While the prevalence of EM AML as per baseline FDG-PET/CT was 23%, we found an estimated prevalence of EM AML of 19% using FDG-PET/CT when including the sensitivity of FDG-PET/CT after histological examination of biopsied lesions. When also adding the three patients with histologically confirmed EM AML, who were initially FDG-PET/CT negative, the combined prevalence of the whole study cohort is 22%. An analysis of only patients with newly diagnosed AML led to a combined prevalence of EM AML of 17% in our study. This is 3-to 11-fold higher than previously reported32 but lower than in other reported studies.18175 Some reports over-estimated the prevalence of EM AML since data were derived from autopsy studies, which have a natural selection in favor of relapsed and/or refractory patients, or because a positive selection in favor of myelomonocytic AML subtypes occurred, as these are known to have a higher likelihood of presenting with EM AML.1817 Other studies under-estimate the prevalence of EM AML because they rely on the clinical findings of EM AML, which only represents the tip of the iceberg.53 Some reports also include EM AML sites in their calculation, such as gingival hyperplasia, splenomegaly or leukemic meningitis, which does not per se fulfill the World Health Organization (WHO) criteria for EM AML and therefore might over-estimate the prevalence of EM AML.191765 A recent retrospective analysis by Ganzel et al. reported a clinical prevalence of 24% and argued that with a PET-based screening the rate of extramedullary AML would be even higher.5 The prevalence of EM AML in our study remains in that range; however, our study and the analysis by Ganzel et al. describe and discuss different EM AML characteristics. Whether leukemic meningitis, gingival hyperplasia, and splenomegaly fulfill the WHO criteria for extramedullary disease remains highly debatable. Disrupted tissue architecture by AML cells (or effaced tissue architecture) cannot be considered exclusively responsible for leukemic meningitis (but as rather resembling blood-brain-barrier migration), gingival hyperplasia (resembling indirect hyperplasia), and splenomegaly (resembling leukemic infiltration not effacing spleen architecture).201 Whether clinical assessment is sufficient, and whether it is necessary to biopsy EM AML, has been the subject of much discussion and controversy.5 However, our data show that a non-negligible proportion of AML patients with EM still harbor FDG-avid manifestations despite being in CR at the same time, as per bone marrow assessment. Since the definition of a CR of AML includes resolution of EM AML, this provides a further argument to perform sensitive FDG-PET/CT imaging in these patients. Furthermore, incidental findings of other hematologic malignancies such as multicentric Castleman’s disease at initial presentation of AML diagnosed in parallel in our study seem to argue for histological confirmation whenever possible. The observation that many patients with EM AML harbor more than one EM site has been suggested in our pilot study and others, and could be confirmed by this study.85 The phenomenon observed here that isolated EM AML of the skin (chloroma) is not necessarily FDG-PET-avid and thus cannot be visualized by FDG-PET/CT imaging has already been reported in our pilot study.8 For these patients FDG-PET/CT imaging might only be useful in identifying additional EM AML sites.

However, all imaging methods have limitations. FDG-PET/CT is limited by the size of an EM AML mass required to emit an FDG-PET signal. Theoretically, a cluster of at least 10 FDG avid cells is needed to meet the spatial resolution of a commercially available human PET machine and to generate a detectable PET signal. Furthermore, an objective of this trial was to include a representative AML patient cohort, since it was designed to estimate the prevalence of EM AML, and not survival differences between patients with EM AML as compared to patients without EM AML. However, 3 of the 9 relapsed AML patients who were included in the trial harbored EM AML as per FDG-PET/CT. In spite of this, the National Comprehensive Cancer Network and others recommend FDG-PET/CT when EM AML is suspected in an AML patient, while the European LeukemiaNet provides no recommendations for doctors treating patients with EM AML.222162

In summary, our study demonstrates a higher prevalence of EM AML than previously reported and assumed, while the clinical prevalence was in the range of previously published reports. We were able to demonstrate thatFDG-PET/CT is feasible and safe in patients with AML at diagnosis. Furthermore, we were able to confirm that, in most patients, more than one metabolically active EM AML manifestation could be detected with FDG-PET/CT. Interestingly, six patients who were PET-positive at baseline and who had histologically confirmed EM AML were in hematologic CR but still had detectable FDG-avid EM AML depicting heterogeneity after treatment (Online Supplementary Figure S1A). When analyzing those four patients who presented with EM AML at diagnosis (as per initial FDG-PET/CT) and frank bone marrow AML, all four were still positive for EM AML as per FDG-PET/CT but in a CR as per bone marrow aspirate; furthermore, three of these four patients eventually relapsed, despite consolidation therapy. The dynamics of PET-positivity with regard to concurrent bone marrow involvement, therefore, seem to be heterogeneous and the prognostic relevance of this has to be studied in further prospective trials. Hence, this study allows further trials to be designed and calculated for a prospective evaluation of the impact of EM AML using FDG-PET/CT.

Acknowledgments

We would like to thank Katrin Rosenow and Gabriele Kotzerke for co-ordinating the FDG-PET/CT procedures. We would like to thank Annett Engmann, Katrin Peschel, and Catrin Theuser for data management. We would like to thank the patients, nurses, and doctors who contributed to this study.

Footnotes

• ↵# MS and KZ contributed equally as co-senior authors.
• Check the online version for the most updated information on this article, online supplements, and information on authorship & disclosures: www.haematologica.org/content/105/6/1552
• FundingThis study was supported by the German Cancer Aid Foundation (109575 to FS, KZ, and MS). Open Access funding by the Publication Funds of the TU Dresden.

• Received March 31, 2019.
• Accepted August 27, 2019.
